This label, on the spare tire cover, has the following information:

- Vehicle Identification Number (VIN).

- Model designation.

- Paint information.

- Production options and special equipment.

2016

Do not remove this label from the vehicle.

See also:

Hoses
Hoses transport fluids and should be regularly inspected to ensure that there are no cracks or leaks. With a multi–point inspection, your dealer can inspect the hoses and advise if replacemen ...

2016 Cadillac Xlr Service Manual

Additional Maintenance and Care
Your vehicle is an important investment and caring for it properly may help to avoid future costly repairs. To maintain vehicle performance, additional maintenance services may be required ...

Entry/Exit Recall
If the vehicle has this feature, it allows you to select your preferred automatic recall of stored memory and exit positions. See Memory Seats for more information. Press the customization ...

CADILLAC TPMS RESET

Manual

Instruction on how to reset the TPMS light / Warning indicator on Cadillac Cars.

Cadillac ATS 2013 TPMS Reset 1
Cadillac ATS 2013 TPMS Reset 1
Cadillac ATS 2013 TPMS Reset 1
Cadillac ATS 2014-2015 TPMS Reset 1
Cadillac ATS 2014-2015 TPMS Reset 1
Cadillac CTS 2014-2015 TPMS Reset 1
Cadillac CTS 2014 TPMS Reset 1
Cadillac CTS 2015-2017 TPMS Reset 1
Cadillac CTS 2016-2018 TPMS Reset 1
Cadillac Escalade 2014 TPMS Reset 1
Cadillac Escalade 2015-2016 TPMS Reset 1
Cadillac SRX 2014 TPMS Reset 1
Cadillac SRX 2015 TPMS Reset 1
Cadillac SRX 2015 TPMS Reset 1
Cadillac XTS 2013 TPMS Reset 1
Cadillac XTS 2014 TPMS Reset 1
Cadillac XTS 2015-2016 TPMS Reset 1
Cadillac Escalade 2004 TPMS Reset 2
Cadillac Escalade 2005-2006 TPMS Reset 2
Cadillac CTS 2004-2007 TPMS Reset 3
Cadillac CTS 2008 TPMS Reset 3
Cadillac CTS 2009-2013 TPMS Reset 3
Cadillac CTS 2009-2013 TPMS Reset 3
Cadillac DTS 2006 TPMS Reset 3
Cadillac DTS 2006 TPMS Reset 3
Cadillac DTS 2007-2011 TPMS Reset 3
Cadillac Escalade 2007 TPMS Reset 3
Cadillac Escalade 2007 TPMS Reset 3
Cadillac Escalade 2008-2013 TPMS Reset 3
Cadillac SRX 2004-2006 TPMS Reset 3
Cadillac SRX 2007-2009 TPMS Reset 3
Cadillac SRX 2010-2013 TPMS Reset 3
Cadillac STS 2005-2008 TPMS Reset 3
Cadillac STS 2009 TPMS Reset 3
Cadillac STS 2009 TPMS Reset 3
Cadillac STS 2010-2011 TPMS Reset 3
Cadillac XLR 2004-2009 TPMS Reset 3
Cadillac ATS 2016-2017 TPMS Reset 4
Cadillac SRX 2016 TPMS Reset 4
Cadillac ELR 2015 TPMS Reset 5
Cadillac ATS 2018 TPMS Reset 5
Cadillac ATS 2018 TPMS Reset 5
Cadillac ATS-V 2013-2018 TPMS Reset 5
Cadillac CT6 2016-2018 TPMS Reset 5
Cadillac CTS 2018 TPMS Reset 5
Cadillac ELR 2014 TPMS Reset 5
Cadillac ELR 2015 TPMS Reset 5
Cadillac ELR 2016 TPMS Reset 5
Cadillac Escalade 2017 TPMS Reset 5
Cadillac XT5 2017 TPMS Reset 5
Cadillac XTS 2017 TPMS Reset 5
Cadillac Escalade 2018 TPMS Reset 6
Cadillac Escalade 2018 TPMS Reset 6
Cadillac XT5 2018 TPMS Reset 6
Cadillac Deville 2001-2005 TPMS Reset 7
Cadillac Seville 2001-2004 TPMS Reset 7

CADILLAC TPMS RESET

CADILLAC TPMS RESET INSTRUCTION 1

Note: TPMS Scan Tool is Necessary when Relearning the TPMS of this Model.

Sensor Relearn Procedure:

1. Inflate all tires to the pressure listed on the placard.
2. Turn ignition to the ON/RUN position with the engine OFF (not the ACC position) and lower the driver’s side window.
3. Scroll to the Tire Pressures screen, using the steering wheel buttons, then hold down the checkmark button until the horn sounds.
4. Starting with the LF tire, use your TPMS scan tool to scan each sensor in the following order: LF, RF, RR and LR. The horn will chirp, after the vehicle has received a signal from each sensor. After activating the LR tire, the horn will chirp twice signifying the relearn is complete.
5. Turn the ignition to the OFF position.

Sensor Relearn Procedure (select models):

1. Inflate all tires to the pressure listed on the placard.
2. Turn ignition to the ON/RUN position with the engine OFF (not the ACC position) and lower the driver’s side window.
3. Press and release the trip odometer button to scroll to the Tire Pressure display.
4. Hold down the trip odometer button for 5 seconds, then press the button again to confirm.
5. Starting with the LF tire, use your TPMS scan tool to scan each sensor in the following order: LF, RF, RR and LR. The horn will chirp, after the vehicle has received a signal from each sensor. After activating the LR tire, the horn will chirp twice signifying the relearn is complete.
6. Turn the ignition to the OFF position.

2016 Cadillac Xlr Service Manual Free

CADILLAC TPMS RESET INSTRUCTION 2

Note: TPMS Scan Tool is Necessary when Relearning the TPMS of this Model.

Procedure using another Properly Formatted TPMS Scan Tool

1. Inflate all tires to the pressure listed on the placard.
2. Turn ignition to the ON/RUN position with the engine OFF (not the ACC position).
3. Turn the headlight switch from OFF to parking lamps 4 times within five seconds. The horn sounds twice to signal the receiver is in relearn mode.
4. Starting with the LF tire, use a properly formatted TPMS scan tool to scan each sensor in the following order: LF, RF, RR and LR. The horn will chirp, after the vehicle has received a signal from each sensor. After activating the LR tire, the horn will chirp twice signifying the relearn is complete.
5. Turn the ignition to the OFF position.

Relearn Procedure for Models Equipped with a Driver’s Information Center (DIC):

1. Inflate all tires to the pressure listed on the placard.
2. Turn ignition to the ON/RUN position with the engine OFF (not the ACC position) and lower the driver’s side window.
3. Press the Vehicle Information button (located to the left or right of the instrument cluster) repeatedly until “LEARN TIRE PRESSURES” is displayed. Then press the checkmark button.
4. Starting with the LF tire, use a properly formatted TPMS scan tool to scan each sensor in the following order: LF, RF, RR and LR. The horn will chirp, after the vehicle has received a signal from each sensor. After activating the LR tire, the horn will chirp twice signifying the relearn is complete.
5. Turn the ignition to the OFF position.

CADILLAC TPMS RESET INSTRUCTION 3

Note: TPMS Scan Tool is Necessary when Relearning the TPMS of this Model.

Relearn Procedure for Models Equipped with Keyless Entry:

1. Inflate all tires to the pressure listed on the placard.
2. Turn ignition to the ON/RUN position with the engine OFF (not the ACC position).
3. Using the keyless entry (key fob), press and hold the lock and the unlock buttonssimultaneously until the horn sounds.
4. Starting with the LF tire, use a properly formatted TPMS scan tool to scan each sensor in the following order: LF, RF, RR and LR. The horn will chirp, after the vehicle has received a signal from each sensor. After activating the LR tire, the horn will chirp twice signifying the relearn is complete.
5. Turn the ignition to the OFF position.

Service

Relearn Procedure for Models Equipped with a Driver’s Information Center (DIC):

1. Inflate all tires to the pressure listed on the placard.
2. Turn ignition to the ON/RUN position with the engine OFF (not the ACC position) and lower the driver’s side window.
3. Press the Vehicle Information button (located to the left or right of the instrument cluster) repeatedly until “LEARN TIRE PRESSURES” is displayed. Then press the checkmark button.
4. Starting with the LF tire, use a properly formatted TPMS scan tool to scan each sensor in the following order: LF, RF, RR and LR. The horn will chirp, after the vehicle has received a signal from each sensor. After activating the LR tire, the horn will chirp twice signifying the relearn is complete.
5. Turn the ignition to the OFF position.

Relearn Procedure for Models NOT Equipped with a Keyless Entry or DIC:

1. Inflate all tires to the pressure listed on the placard.
2. Turn ignition to the ON/RUN position with the engine OFF (not the ACC position) and lower the driver’s side window.
3. Press the trip odometer button until “LEARN TIRE PRESSURES” is displayed. Then hold down the trip odometer button until the horn chirps.
4. Starting with the LF tire, use a properly formatted TPMS scan tool to scan each sensor in the following order: LF, RF, RR and LR. The horn will chirp, after the vehicle has received a signal from each sensor. After activating the LR tire, the horn will chirp twice signifying the relearn is complete.
5. Turn the ignition to the OFF position.

CADILLAC TPMS RESET INSTRUCTION 4

Note: TPMS Scan Tool is Necessary when Relearning the TPMS of this Model.

Sensor Relearn Procedure with Steering Wheel Buttons:

1. Ensure all tires are inflated to the pressures listed on the tire placard.
2. Turn the ignition switch to the ON position (engine off) and lower the driver side window.
3. Scroll to the Tire Pressure screen using the steering wheel buttons then hold down the checkmark button until the horn sounds.
4. Starting with the LF tire, use a properly formatted TPMS scan tool to scan each sensor in the following order: LF, RF, RR and LR. The horn will chirp, after the vehicle has received a signal from each sensor. After activating the LR tire, the horn will chirp twice signifying the relearn is complete.
5. Turn ignition to the OFF position.

Sensor Relearn Procedure not equipped with Steering Wheel Buttons:

Cadillac xlr v

1. Ensure all tires are inflated to the pressures listed on the tire placard.
2. Turn the ignition switch to the ON position (engine off) and lower the driver side window.
3. Press and release the trip odometer button to scroll to the Tire Pressure display.
4. Hold down the trip odometer button for five seconds then press the button again to confirm.
5. Starting with the LF tire, use a properly formatted TPMS scan tool to scan each sensor in the following order: LF, RF, RR and LR. The horn will chirp, after the vehicle has received a signal from each sensor. After activating the LR tire, the horn will chirp twice signifying the relearn is complete.
6. Turn ignition to the OFF position.

CADILLAC TPMS RESET INSTRUCTION 5

Note: TPMS Scan Tool is Necessary when Relearning the TPMS of this Model.

Sensor Relearn Procedure with Steering Wheel Buttons:

2016 Cadillac Xlr Service Manual Pdf

1. Ensure all tires are inflated to the pressures listed on the tire placard.
2. Start the Vehicle.
3. Using the streering wheel’s keypad, select “Settings,””Display Options,” then “Tire Pressure” to turn on the Tire Pressure readout display”
4. Exit the “Settings” menu and scroll to the Tire Pressure Screen.
5. Hold down the SEL/Checkmark button until the horn sounds twice.
6. Starting with the LF tire, use your TPMS Scan Tool to scan each sensor in the following order: LF, RF, RR and LR. The horn will chirp, after the vehicle has received a signal from each sensor. After activating the LR tire, the horn will chirp twice signifying the relearn is complete.
7. Shut the vehicle off.

CADILLAC TPMS RESET INSTRUCTION 6

Note: TPMS Scan Tool is Necessary when Relearning the TPMS of this Model.

2016 Cadillac Xts Manual Pdf

Sensor Relearn Procedure with Steering Wheel Buttons:

1. Ensure all tires are inflated to the pressures listed on the tire placard.
2. Set the Parking Brake
3. With the vehicle off, hold down the ignition button for 5 seconds
a. Do not press the brake pedal while holding down the ignition button
4. Using the streering wheel’s keypad, select “Settings,””Display Options,” then “Tire Pressure” to turn on the Tire Pressure readout display”
5. Exit the “Settings” menu and scroll to the Tire Pressure Screen.
6. Hold down the SEL/Checkmark/ or scroll‐wheel until the horn sounds twice.
7. Starting with the LF tire, use your TPMS Scan Tool to scan each sensor in the following order: LF, RF, RR and LR. The horn will chirp, after the vehicle has received a signal from each sensor. After activating the LR tire, the horn will chirp twice signifying the relearn is complete.
8. Shut the vehicle off.

CADILLAC TPMS RESET INSTRUCTION 7

2005 Cadillac Xlr Service Manual

A relearn magnet, or another properly formatted TPMS scan tool, is required to perform this procedure.

Relearn Procedure.

1. Inflate all tires to pressure listed on the placard.
2. Turn ignition to the ON/RUN position with the engine OFF.
3. Using the keyless entry (key fob), press and hold both the lock and the unlock buttons simultaneously until the horn sounds.
4. Starting with the left front tire, place the relearn magnet over valve stem until the horn sounds.
5. After the horn chirp has sounded, proceed as in step 4 for the next three sensors in the following order: RF, RR, and LR. The horn will sound after each activation. After activating the LR sensor, the horn will sound twice signifying the relearn is complete.
6. Turn the ignition switch to OFF to exit the relearn mode.
